Hytera HP 602 Two-Way Radio Deep Dive Overview

Hytera HP 602 Two-Way Radio Deep Dive Overview

February 3, 2026

On this page

Core Features of the Hytera HP602 Two-Way Radio

  • Audio Quality: Features a large, forward-facing speaker and AI-based noise cancellation technology that can decrease unwanted background noises by up to 30dB. It also uses water-porting technology to drain water from the speaker cavity, ensuring audio clarity in wet conditions.
  • Ruggedness and Durability: The radio is fully compliant with IP67 standards for dust and water ingress (submersible in 1 meter of water for 30 minutes) and meets MIL-STD-810G standards for shock, vibration, and extreme temperatures.
  • Battery Life: A powerful and lightweight 2000mAh Lithium Polymer battery provides an extended life of up to 20 hours of operation (on a 5/5/90 duty cycle, GPS disabled).
  • Worker Safety: Includes several features to enhance user safety, such as a programmable emergency button, Lone Worker prompts, and a Man Down feature that automatically triggers an alert if the radio is inclined at a pre-set angle or motionless for a period of time.
  • Connectivity and Systems: Supports dual-mode operation (both analog and digital modes) to facilitate seamless migration from older systems. It also features built-in Bluetooth for audio and data connectivity to wireless accessories and, in specified models, GPS for real-time location tracking.
  • Security: Supports digital end-to-end encryption (ARC4 and AES algorithms) for secure voice and data transmissions, as well as radio authentication to prevent unauthorized system access.
Hytera HP602 Um Two-Way Radio, 4W, 1024C, Analog/DMR, IP67, MD, 1-Line Display, UHF(400-527MHz) - H08

Hytera HP602 Um Two-Way Radio, 4W, 1024C, Analog/DMR, IP67, MD, 1-Line Display, UHF(400-527MHz) - H08

1) Loud , Clear Audio for Noisy Environments

When communication is competing with machinery, crowds, or echo-filled hallways, you need a radio that can cut through the noise
  • Louder and Clearer Audio Hytera provides industry-leading audio quality through a large forward-facing speaker, and AI based voice enhancement with deep learning ability that can accurately extract voice from noise in real time and decreases unwanted background noises as loud as 30db. Acoustic feedback suppression prevents howling when multiple radios are in close proximity. New water-porting technology quickly drains water out of speaker cavity to maintain audio clarity. Thinner and Lighter An optimized mechanical design with advanced materials, and a lightweight lithium polymer battery delivers a compact radio that weighs less than 10 ounces.

2) Rugged Durability for Real Work Conditions

  • Higher Level of Ruggedness The HP6 Series is fully compliant with the IP68 and MIL-STD- 810 G standards. It is dustproof, water resistant, and can stand up to drop shock testing at 2 meters. The HP6 Series anti-magnetic speaker does not attract magnetic metal dust and shavings.

3) Full-Shift Power for All-Day Operations

  • Longer Battery Life The latest in lithium polymer battery technology is used to power the HP6 Series radios for excellent performance. The battery is light and small, achieving a shift life of 20 hours on high transmit power with a duty cycle of 5/5/90.

4) Safety features

  • Enhanced Worker Safety The HP6 Series feature programmable emergency buttons, emergency calling, and priority interrupt.
  • Lone Worker prompts the user to press a key or speak to indicate they are safe.
  • Man Down allows the radio to automatically enter emergency mode when the radio is inclined at a pre-set angle or remains motionless.
  • Hearing protection prevents the maximum volume when using audio earpieces.
  • The HP602 features a 0.91-inch OLED display that shows the channel, signal strength, power status, and power level.

5) Expanded features Hytera H Series Two-Way Radios

  • Å Enhanced GPS Location Tracking The HP682 and HP602 radios can report current location information to other radios, the dispatcher, or third-party applications in real time, enhancing the efficiency of visualized dispatch applications. GPS data can be transmitted during voice calls for immediate location targeting, and GPS data can be compressed to increase channel capacity and reduce hardware cost.
  • Higher Security The HP6 Series supports Digital End-to-End and Over-the-Air Encryption for voice and data transmitted on digital channels to prevent eavesdropping. Hardware encryption is implemented through a built-in encryption card. Software encryption uses the secure and reliable ARC4 and AES encryption algorithms. Radio authentication prevents unauthorized users from accessing the system. If a radio is lost or stolen, the system can Stun or Kill the radio to prevent unauthorized use.
  • Greater Calling Flexibility A variety of calling modes provides the flexibility to communicate with any or all users. The HP6 Series supports Individual Calls (radio to radio, radio to dispatcher), Group Calls (one radio to many, dispatcher to many), Unaddressed Group Calls (a single call to multiple groups), All Call (broadcast call to all radios, transmit only), and Telephone Calls (with connectivity to PSTN, PABX, or SIP networks).
  • Multi-System Operation The HP6 Series can be deployed in a wide variety of analog and digital radio networks, including Analog and Digital Conventional, MPT and XPT Trunking, DMR Tier II Trunking, IP Multi-Site Connect, and DMR Simulcast Systems. Extended Coverage and Connectivity The HP6 Series extends radio range through increased Tx power, Rx sensitivity, improved antenna gain, and reduced attenuation. This produces a 25% increase in coverage distance and signal penetration through buildings. The enhanced coverage improves efficiency and reduces network infrastructure costs. Two patented technologies and a voice buffer reduces packet loss during Rx handover for consistently clear calls and fewer dropped words. Bluetooth Built-in Bluetooth supports both audio and data, and enables connectivity to wireless accessories like earpieces and microphones.
  • DTMF Signaling DTMF is a system of analog tonal signals that enables routing telephone calls to radio networks. DMTF is also used to control physical devices such as irrigation systems, motorized gates and doors, and other devices. The HP6 radios can send DTMF signals manually (with HP682 keypad) or send up to 256 stored pre-programmed
  • Visual Overview of the Hytera HP Series features
Hytera HP602 Two-Way Radio - H Series
Hytera HP602 Two-Way Radio - H Series

Core Use Cases and Industries:

  • Public Safety and Security: Ideal for security personnel due to its discreet design, one-line OLED display, and dedicated emergency button, allowing for fast, covert communication.
  • Construction and Industrial Fieldwork: Designed to withstand drops, dust, and rain (IP68, MIL-STD-810G). Its anti-magnetic speaker is suitable for environments with metal shavings, while high-power transmission ensures coverage across large sites.
  • Manufacturing and Warehousing: Facilitates efficient coordination, with long-lasting battery life (20-24 hours) for full shifts and clear audio in high-noise areas.
  • Logistics and Transportation: Supports GPS location tracking for real-time fleet management and dispatch, with enhanced range for connectivity over large areas.
  • Hospitality and Event Management: Suitable for staff coordination, offering Bluetooth for wireless accessories (earpieces) to keep communication discreet, and covering, for example, large hotel properties and casinos.

Key Operational Features:

  • Worker Safety: Includes Man Down
  • Clear Audio & Range: Delivers 25% better coverage than standard radios and filters out background noise for,, in some cases, enhanced communication in loud environments.
  • Versatile Calling: Supports individual, group, and all-calls for flexible communication, along with support for analog and digital modes.

Range Expectations:

Real-world coverage varies significantly based on:
  • Building materials (concrete, steel, glass), floor plan, and interference
  • Whether you’re using repeaters
  • Antenna placement and how radios are carried/used

FCC Licensing

This is a business-band UHF radio. Most business use cases require appropriate FCC licensing and correct frequency programming. If you’re replacing an existing fleet, the simplest path is typically matching your current licensed frequencies. If you’re starting fresh, plan for licensing and legal frequency coordination as part of deployment.
FCC License

FCC License

How to Get Started

  1. Identify your environment: warehouse, hotel, jobsite, campus, or mixed use
  2. Confirm compatibility needs: matching existing radios/frequencies vs. new deployment
  3. Plan channels and zones: organize by department and workflow
  4. Decide on accessories: spares, chargers, headsets, speaker mics, cloning cable
  5. Handle licensing and programming: set radios up correctly before rollout
